Perfusafe2

Description

Perfusafe2 is a safety infusion device with Huber bevel for implantable ports which can be used for intermittent injections, continuous infusions of… Read more

Indication

Safety infusion device which can be used with any implantable port (Sitimplant, Mini-Sitimplant, Micro-Sitimplant, Heliosite and any other port...) allowing blood samplings, intermittent injections or continuous infusions of drugs or fluids.

When Perfusafe2 is removed from an implantable port, the needle is automatically directed onto a safety block offering total protection for health care workers.

See all references

Need more information?

Send a request

Instructions for use

Product highlights

Patient & caregiver comfort:
Perfusafe2's minimal profile provides stability. For patient comfort, the lower wings, which are in contact with the skin, are soft and flat. The upper wings are grooved for a good grip. The device's transparency enables the caregiver to visualize the puncture site and monitor any complications.

Compatible with high-pressure injections up to 350 psi:
Perfusafe2 is compatible with MRI procedures and contrast media injection. Gauge, perfusion rate and maximum pressure supported by the needle are indicated on the needle clamp.

Prevention of Needle Stick Injuries (NSI):
Perfusafe2 safety Huber needle prevents accidental punctures during removal, and thus the risk of NSI. The needle is automatically directed towards a safety trap, protecting nursing staff without modifying normal puncture techniques.

From paediatric to adults: Perfusafe2 is part of a wide range of Huber needles to suit all patient morphologies:

3 gauges (22G, 20G and 19G)
4 lengths (15, 20, 25, 30 mm).

Perfusafe2 is available with or without a Y site.

The Huber needle Perfusafe2 is a sterile medical device of class IIa.
Certification established by GMED, notified body n°0459.
They are indicated for the administration into or withdrawal of fluids from implanted ports.
Read the instructions for use carefully.
Device manufactured and distributed by VYGON.

Description

Perfusafe2 is a safety infusion device with Huber bevel for implantable ports which can be used for intermittent injections, continuous infusions of drugs or solutions, blood sampling ...

Perfusafe2 consists of:

1 needle with Huber bevel. Four lengthes of needle are available: 15mm, 20mm, 25mm and 30mm,
4 wings: 2 upper wings for gripping and holding the device during placement and removal. 2 lower wings to hold the implantable port in place when removing Perfusafe2 and activate the safety mechanism,
1 flexible extension tube in polyurethane, length 215mm - Int.-ext. Ø: 1.5x2.5mm
1 female Luer-lock hub
1 male Luer-lock cap
1 color-coded clamp according to the size of the needle
1 protection pad

Perfusafe2 prevents needle-stick injuries by rebound effect when withdrawing a Huber needle from an implantable port.
The needle is automatically directed into a safety block offering total protection for health care workers with no change in the handling technique for the operator.

Perfusafe2 can be used for high pressure injections of contrast medium (CT-scan) up to 350 psi.

Perfusafe2 is also available in the following versions:
Perfusafe2 codes 5249.116/.121/.126/.716/.721/.726/.916/.921/.926 have an Autoflush on the proximal hub of the device and no lateral injection site.
Perfusafe2 codes 5249.117/.122/.127/.132/.717/.722/.727/.732/.917/.922/.927/.932 have a Bionector on the proximal hub of the device and no lateral injection site.
Perfusafe2 codes 5250.115/.120/.125/.130/.715/.720/.725/.730/.915/.920/.925/.930 have a lateral injection site fitted with an Autoflush.
Perfusafe2 codes 5250.117/.122/.127/.132/.717/.722/.727/.732/.917/.922/.927/.932 have a lateral injection site fitted with a Bionector.

N.B. Latex-free product compatible with drugs containing lipids (such as Taxol)

References and Features

		Perfusafe2				Packaging
Favourites	Code	Length mm	Ext. Ø mm	G	Colour code	Units/Box	Units/Case
	5249.115	15	1.1	19	-	10	90
	5249.120	20	1.1	19	-	10	90
	5249.125	25	1.1	19	-	10	90
	5249.130	30	1.1	19	-	10	90
	5249.715	15	0.7	22	-	10	90
	5249.720	20	0.7	22	-	10	90
	5249.725	25	0.7	22	-	10	90
	5249.730	30	0.7	22	-	10	90
	5249.915	15	0.9	20	-	10	90
	5249.920	20	0.9	20	-	10	90
	5249.925	25	0.9	20	-	10	90
	5249.930	30	0.9	20	-	10	90
	5250.115	15	1.1	19	Cream	10	90
	5250.120	20	1.1	19	Cream	10	90
	5250.125	25	1.1	19	Cream	10	90
	5250.130	30	1.1	19	Cream	10	90
	5250.715	15	0.7	22	Black	10	90
	5250.720	20	0.7	22	Black	10	90
	5250.725	25	0.7	22	Black	10	90
	5250.730	30	0.7	22	Black	10	90
	5250.915	15	0.9	20	Yellow	10	90
	5250.920	20	0.9	20	Yellow	10	90
	5250.925	25	0.9	20	Yellow	10	90
	5250.930	30	0.9	20	Yellow	10	90
